A Boolean operation is a Boolean function taking truth values encoded as bits: $0$ means false and $1$ means true. These operations supply the concrete two-valued interpretation of a Boolean algebra. A Boolean valuation fixes the inputs; a truth table lists every possible input. With two input bits there are four rows.

The basic logical connectives are logical conjunction (AND, $P\wedge Q$, both true), logical disjunction (OR, $P\vee Q$, at least one true), exclusive or (XOR, $P\oplus Q$, exactly one true), and logical negation (NOT, $\neg P$, the opposite value). OR is inclusive: it accepts the case where both inputs are true.^[ref]

For an original program-condition example, let $P$ mean “the backup is recent” and $Q$ mean “the backup is verified”. A rule requiring a recent, verified backup uses logical conjunction; one accepting either qualification uses logical disjunction. A rule flagging a mismatch between the two qualifications uses exclusive or. A recent, verified backup gives $(P,Q)=(1,1)$: AND and OR accept it, while XOR does not flag it. The last row of the truth table makes this difference explicit.

The same small Boolean operations build larger tests and Boolean circuits. In a programming language, the value of a condition and the procedure for evaluating it both matter. For Boolean operands, Python's and, or, and not implement these logical connectives. Evaluation proceeds from the left; and skips its right operand if the left is false, and or skips it if the left is true. More generally, and and or return an operand, whereas not returns a Boolean.^[ref]

For example, the Python condition denominator != 0 and numerator / denominator > 2 avoids division by zero because the logical conjunction's second test is evaluated only when the first succeeds. Reversing the tests preserves the abstract truth table for defined operands but can raise a division-by-zero error handled through exception handling. A rewrite involving a side effect must also preserve the needed evaluation behavior.

De Morgan's laws exchange logical conjunction and logical disjunction when a logical negation moves across them:Here $\equiv$ denotes logical equivalence: the two propositional formulas agree under every Boolean valuation.^[ref]

A complete verification uses the four rows of a truth table. In input order $(0,0),(0,1),(1,0),(1,1)$, both sides of the first logical equivalence have output sequence $(1,1,1,0)$; both sides of the second have $(1,0,0,0)$. A proof in words is equally short: failure of “both” means at least one failure, whereas failure of “at least one” means both fail. The differing middle rows explain why simply pushing logical negation inward without changing AND to OR is wrong.

For the events in Boolean operations on events, the corresponding set identities areOne can prove these identities by checking an arbitrary set element $u\in U$: its two membership truth values obey De Morgan's laws. The same reasoning works for any two subsets of a common universal set.

For a nested program test, let $R$ mean “backup recent”, $V$ mean “backup verified”, and $O$ mean “manual override authorized”. Rejecting when neither an acceptable backup nor an override is present givesThe transformed condition reads “backup stale or unverified, and no override”. Apply the second of De Morgan's laws at the outside, then the first at the inner logical conjunction. For $(R,V,O)=(1,0,0)$ it rejects; changing only $O$ to one makes it accept. With Boolean operands in Python, not ((recent and verified) or override) and ((not recent) or (not verified)) and (not override) have the same result and inspect the operands in the same order, with the same skipped operands.
