Double cover of the sphere with four branch values ($d=2,R_f=4,g_X=1$)

Suppose a nonconstant holomorphic map $f:X\to {\mathbb{P}}^1$ from a connected compact Riemann surface has degree of a holomorphic map two and exactly four distinct branch values of a holomorphic map. The valency theorem forces each of their fibres to contain one ramification point with $e_p=2$, a simple ramification point of a holomorphic map. HenceThis determines the genus without recognizing a torus in a drawing.

A concrete realization is the compact Riemann surface obtained by adding the two points at infinity to the even-degree hyperelliptic model given by the algebraic curveProjection to $z$ has degree of a holomorphic map two. At a simple zero $a$ of $P$, $w$ is a local coordinate and $z-a=w^2/P^{\prime }(a)+O(w^4)$, so $e_p=2$. At infinity set $u=1/z$ and $s=w/z^2$: then $s^2=(1-4u^2)(1-u^2)$. There are two points with $u=0$, $s=\pm 1$, each unramified since $u$ is a local coordinate. The four finite roots are therefore all the branch values of a holomorphic map.^[ref]

Choose a triangulation of a surface on the Riemann sphere with these four branch values of a holomorphic map as vertices, combinatorially the boundary of a tetrahedron. Its counts are $V=4,E=6,F=4$. Upstairs, each vertex has one preimage and each open edge and face has two lifts: $V_X=4,E_X=12,F_X=8$, giving Euler characteristic $4-12+8=0$. This is a cell schematic, not a geometric immersion of $X$. The Triangulation proof of the Riemann-Hurwitz formula applies the same counting idea after refining a general triangulation of a surface around the branch values of a holomorphic map.^[ref]
