An annihilation operator lowers the occupation number operator eigenvalue by one and annihilates the Fock vacuum.

A Bogoliubov vacuum is annihilated by the quasiparticle linear operators that diagonalize a stable quadratic bosonic Hamiltonian. If $a_k=u_k{b}_k-v_k{b}_{-k}^{†}$, its original-mode occupation number is $|v_k{|}^2$. It is generally a multimode squeezed vacuum rather than the original Fock vacuum. In infinitely many modes, existence in the original Fock space requires a separate convergence analysis.

For two equal-energy bosonic species with annihilation operators $a,b$, set $c_{-}=(a-b)/\sqrt{2}$ and let $N_{-}$ be its number operator. Since $[N_{-},c_{-}]=-c_{-}$, conjugation by $e^{i\pi N_{-}}$ reverses the antisymmetric combination while fixing $(a+b)/\sqrt{2}$, and therefore exchanges $a,b$ and their creation operators. For the particle and antiparticle modes of a complex scalar field this realizes charge conjugation, fixes the Fock vacuum, and squares to one. The normal-ordered generator $\int (a^{†}-b^{†})(a-b)$ equals $2N_{-}$. Writing the annihilation factors first adds an infinite constant in the continuum, which must be subtracted or regulated before defining its exponential.

On the real Klein-Gordon field solution space with conserved symplectic form $\Omega$, a compatible real-linear map $J$ obeys $J^2=-I$, preserves $\Omega$, and makes $\mu (f,g)=\Omega (f,Jg)$ positive definite. Its $+i$ eigenspace in the complexified space has positive Klein-Gordon inner product with the convention $(u,v{)}_{KG}=i\Omega (\bar{u},v)$. It defines the one-particle Hilbert space and a free-field Fock vacuum.

The covariant free-photon oscillator construction uses four polarization vectors and $[a^{\lambda },a^{{\lambda }^{\prime }†}]=-{\eta }^{\lambda {\lambda }^{\prime }}$. Starting from a positive Fock vacuum, it induces an indefinite Hermitian form on the multiparticle state space: the temporal oscillator has negative norm while the three spatial oscillators have positive norm. It is therefore not the physical positive Hilbert space. The Gupta-Bleuler null-state quotient selects a positive physical space with two transverse photon polarizations. Continuum momentum oscillators and their states are understood after smearing or finite-volume regularization.

The Hadamard condition requires the two-point function of a physical free-field state to have the universal local short-distance singularity prescribed by the spacetime geometry and field equation. It permits state-dependent smooth contributions and enables local renormalization of the stress-energy tensor. It does not select a unique Fock vacuum.

A phase-selected Hermitian field observable. With annihilation operator $a$ and $[a,a^{†}]=1$, define $X_1=(a+a^{†})/2$ and $X_2=(a-a^{†})/(2i)$. Then $[X_1,X_2]=i/2$ and the Fock vacuum has variance $1/4$ in either quadrature. This dimensionless convention gives $X_{\vartheta }=X_1\cos \vartheta +X_2\sin \vartheta$. Balanced homodyne detection selects $\vartheta$ through the reference wave phase.

Use the unitary discrete Fourier transformThe transformed operators obey $[a_k,a_q^{†}]={\delta }_{kq}$. The hopping terms contribute $2A\cos k$ to the number coefficient. In the pairing sum, the odd sine part cancels between $k$ and $-k$. ThuswhereThe factor one half in the full momentum sum avoids counting an anomalous pair twice. For $H_f>0$, ${\alpha }_k>|{\Delta }_k|$ for every allowed momentum. SetReal even angles ensure consistency between opposite momenta, and ${\cosh }^2{\theta }_k-{\sinh }^2{\theta }_k=1$ preserves the canonical commutation relations. The anomalous coefficient becomes ${\Delta }_k\cosh 2{\theta }_k-{\alpha }_k\sinh 2{\theta }_k=0$. Normal ordering then giveswithThe field-polarized planar ferromagnetic spin wave has energy gap $ϵ(0)=S\sqrt{H_f(H_f+2J)}$. The momenta run over the whole Brillouin zone once, including the self-inverse momenta $0$ and, for even $L$, $\pi$; these use single-mode squeezing rather than introducing an extra independent partner.

The zero-field case has a zero-mode obstruction to bosonic Bogoliubov diagonalization. Its nonzero-momentum modes have $ϵ(k)=2\sqrt{2}JS|\sin (k/2)|$, but ${\alpha }_0={\Delta }_0=JS$, so no finite squeezing angle exists for the uniform mode. With $Q_0=(a_0+a_0^{†})/\sqrt{2}$, its Hamiltonian is $JS{Q}_0^2-JS/2$, not an identically zero oscillator. For example, its matrix element between the vacuum and the two-boson number state is $JS/\sqrt{2}$, whereas $ϵ(0)b_0^{†}{b}_0$ would vanish. Consequently the requested oscillator diagonalization is literal for nonzero field; at zero field treat the collective orientation separately or introduce a field regulator before taking a limit.

For nonzero field, the spin-wave ground state is the vacuum of all $b_k$. The inverse Bogoliubov transformation gives $⟨a_k^{†}{a}_q⟩={\delta }_{kq}{\sinh }^2{\theta }_k$ and vanishing one-point oscillator averages. Translational invariance therefore gives the depletionRotating back to the physical axes yields, to the retained spin-wave order,The zero transverse components also follow from rotation by $\pi$ about the physical $x$ axis in a symmetry-preserving ground state. The nonzero depletion describes zero-point quantum fluctuations: the original boson vacuum is not the ground state because the anomalous terms create pairs. It is nonnegative and must satisfy $\delta S\ll S$ for the expansion to be reliable. At strong field it tends to zero, with $\delta S\sim J^2/(8H_f^2)$ in the infinite-chain limit.

For fixed $H_f>0$, the momentum sum has a finite thermodynamic limit obtained by $L^{-1}{\sum }_k\to (2\pi {)}^{-1}{\int }_{-\pi }^{\pi }dk$. At zero field the uniform mode already has no oscillator vacuum, as explained in part d. Even after removing that mode, the nonzero modes behave asThus assigning a finite ordered moment by simply setting $h=0$ in the infinite momentum sum is invalid. The divergence indicates failure of this expansion about a fixed planar orientation; it is not a negative physical magnetization. At finite size an exact zero-field state chosen to have definite total $S^z$ has zero planar one-point magnetization by the continuous rotation symmetry. Establishing its full correlations requires a treatment beyond the divergent ordered-state approximation.

With no pairing, the Hamiltonian is diagonal in the fermionic occupation numbers. The Pauli exclusion principle allows each momentum mode to be either empty or occupied once. Without a fixed fermion number constraint, occupying a mode lowers the energy precisely when its single-particle energy is negative. Therefore, with $|0⟩$ the Fock vacuum, a ground state isChoose a fixed ordering of the fermionic creation operators; changing it alters only the overall phase. Any zero-energy modes may be occupied or empty without changing the ground-state energy.

To identify the occupied modes, complete the square:Here $\beta$ is the dispersion parameter, not inverse temperature. If ${\beta }^2<4\mu$, every mode has positive energy and the unique ground state is the Fock vacuum, with $E_{\mathrm{GS}}=0$. If ${\beta }^2=4\mu$, there are still no negative-energy modes, but $p=\pm \sqrt{\beta /2}$ have zero energy if they lie on the allowed momentum grid. Each such mode doubles the ground-state degeneracy.

For ${\beta }^2>4\mu$, defineBoth are positive, and the occupied Fermi sea consists of the two intervals $p_{-}<|p|<p_{+}$. With $p=2\pi n/L$, the requested finite-size ground-state energy is explicitlyThe factor two counts opposite momenta. Endpoints are excluded from this sum because they have zero energy; when an endpoint is allowed, its optional occupation adds ground-state degeneracy. A narrow negative-energy interval can contain no allowed finite-size momenta, in which case the sum is empty. The zero-momentum mode is always empty since $ϵ(0)=\alpha \mu >0$.

Treat $\varphi ,{\varphi }^{†}$ as independent variables when taking the Legendre transform. Their canonical momenta areThe canonical quantization of a complex scalar field imposes, at equal times,with $[\varphi ,{\varphi }^{†}]=[\varphi ,\varphi ]=[\pi ,{\pi }^{†}]=[\pi ,\pi ]=0$, together with their adjoints, and $[\varphi ,{\pi }^{†}]=[{\varphi }^{†},\pi ]=0$. These are canonical commutation relations for two real scalar degrees of freedom, written in a complex basis. Local fields are operator-valued distributions, so these identities are understood after smearing or with a regulator.

The Hamiltonian density is $\pi \dot{\varphi }+{\pi }^{†}{\dot{\varphi }}^{†}-\mathcal{L}$, givingThe Heisenberg equation of motion is $\dot{O}=i[H,O]$. For example, $i[\int {\pi }^{†}\pi ,\varphi ]={\pi }^{†}$, while commuting $\pi$ with the gradient term and integrating its derivative of a Dirac delta distribution gives ${\nabla }^2{\varphi }^{†}$. ThusBoth fields satisfy the Klein-Gordon equation. Their spatial Fourier modes therefore have frequencies $\pm E_p$, $E_p=\sqrt{{\mathbf{p}}^2+m^2}$. A complex scalar field has independent coefficients for these two frequency sectors, so, defining the invariant measure $d{\Pi }_p=d^{3}p/[(2\pi {)}^{3}2E_p]$, its mode expansion isOne can recover the mode operators at any fixed time using complex scalar mode inversion:Substitution of the expansion verifies these inverses: the spatial integral selects the appropriate momentum, while the two frequency sectors acquire factors $E_p\pm E_q$. The unwanted sector vanishes when the delta function sets $E_p=E_q$. The canonical commutation relations then give, for example,Likewise $[b(p),b^{†}(q)]$ has the same value. The cross commutators vanish; their coefficients contain $E_p-E_q$ on the corresponding momentum delta function. Conversely, these oscillator brackets reproduce the equal-time field brackets, confirming the normalization of the measure.

Insert the mode expansion into $H$ and integrate over space. The terms $a^{†}{b}^{†}$ and $ba$ enforce opposite spatial momenta; their coefficient is $-E_p^2+{\mathbf{p}}^2+m^2=0$. For the diagonal terms the coefficient is $E_p^2+{\mathbf{p}}^2+m^2=2E_p^2$. Combining this with the two invariant measures leavesIn a box, $E_0={\sum }_{\mathbf{p}}{E}_p$, one half-quantum for each of the two real oscillator species. It diverges as the cutoff is removed. Normal ordering removes this vacuum energy, yielding the normal-ordered Hamiltonian of a free complex scalar field:In this nongravitational free theory an additive constant in $H$ changes only an overall state phase, not Heisenberg equations of motion, energy differences or scattering probabilities. It is therefore consistent to choose the Fock vacuum energy as zero. Both creation operators raise the energy: $[H,a^{†}(p)]=E_p{a}^{†}(p)$ and $[H,b^{†}(p)]=E_p{b}^{†}(p)$. Repeated creation builds a bosonic Fock space of spin-zero particles and antiparticles, with the same positive mass and energy. The negative-frequency part of the field does not describe negative-energy physical particles.

The global phase symmetry of a complex scalar field, with orientation $\varphi \mapsto e^{-i\alpha }\varphi$, has the indicated Noether current. Taking its divergence, the two first-derivative terms cancel, givingThe same calculation holds for its normal-ordered version. Integrating its temporal component gives a conserved charge when spatial boundary flux vanishes.

Here the ordering convention is important. Direct substitution into the literally ordered product $i\int ({\varphi }^{†}\dot{\varphi }-{\dot{\varphi }}^{†}\varphi )d^{3}x$ yieldsThe pair terms again vanish, now because their coefficient is a difference of equal energies. Reordering the $b$ term produces a divergent vacuum constant: with a finite-mode regulator $Q_{\mathrm{bare}}=N_a-N_b-N_{\mathrm{modes}}$. Thus the requested finite charge formula uses zero vacuum charge, or equivalently the vacuum subtraction of a complex scalar charge. With that conventional subtraction,The subtraction changes neither current conservation nor the action of $Q$ on fields; without it, the unrenormalized product does not literally equal the displayed normal-ordered operator.

Finally the oscillator commutators giveor $\boxed{Q{a}^{†}=a^{†}(Q+1),Q{b}^{†}=b^{†}(Q-1)}$. Acting on a charge eigenstate, the first creator raises its charge by one and the second lowers it by one. Starting from the neutral Fock vacuum, their one-particle states therefore have charges $+1$ and $-1$ respectively. This is the complex scalar charge operator $N_a-N_b$, whereas the energy counts the sum of the two occupations. A multiparticle state has additive charge equal to the number of particles minus the number of antiparticles.

Use units $\hslash =c=1$ and the Minkowski metric $g=\mathrm{diag}(1,-1,-1,-1)$. The canonical momentum of the real scalar field is $\pi =\partial \mathcal{L}/\partial \dot{\varphi }=\dot{\varphi }$. Canonical quantization replaces the classical fields by operator-valued distributions and imposes the equal-time canonical commutation relationsThese relations are imposed on an initial slice, with smeared fields understood. In the Heisenberg picture, simultaneous unitary time evolution of both operators preserves their commutators. Since the momentum is $\dot{\varphi }$, the requested equal-time commutator is $[\varphi (t,\mathbf{x}),\dot{\varphi }(t,\mathbf{y})]=i{\delta }^{(3)}(\mathbf{x}-\mathbf{y})$.

The Legendre transform in mechanics, applied pointwise, gives the canonical Hamiltonian density of a real scalar field. ThusTo obtain its dynamics rather than assume them, use the Heisenberg equation of motion $\dot{O}=i[H,O]$. The momentum-square term gives $[H,\varphi ]=-i\pi$. The field-square term gives $[H,\pi ]=i{m}^2\varphi$, while differentiating the Dirac delta function in the gradient term and integrating by parts gives $[H,\pi ]=-i{\nabla }^2\varphi +i{m}^2\varphi$. ConsequentlyBoundary terms vanish for suitably decaying smeared fields. This is the Klein-Gordon equation as an operator identity.

A spatial Fourier transform reduces the Klein-Gordon equation to ${\ddot{\varphi }}_{\mathbf{p}}+E_p^2{\varphi }_{\mathbf{p}}=0$, where $E_p=\sqrt{{\mathbf{p}}^2+m^2}$. Its two frequency branches and the Hermitian adjoint condition giveThe invariant-normalized scalar mode extraction can be written particularly simply asSubstituting the mode expansion of a free field proves these inversion formulas: the opposite-frequency coefficient is proportional to $E_p-E_q$ and vanishes after spatial Fourier inversion. Alternatively they are the corresponding Klein-Gordon inner products. Taking their commutators using the equal-time fields gives $(E_p+E_q)(2\pi {)}^3{\delta }^{(3)}(\mathbf{p}-\mathbf{q})$ in the mixed case. In the two equal-type cases the delta function enforces $\mathbf{q}=-\mathbf{p}$, multiplying $E_p-E_q=0$. ThereforeConversely these mode commutators reproduce $[\varphi ,\dot{\varphi }]=i{\delta }^{(3)}$: the two frequency contributions each supply half the spatial Dirac delta function.

For the covariant oscillator Hamiltonian of a real scalar field, insert the mode expansion of a free field into $H$. Spatial integration sets the two momenta equal in the mixed terms and opposite in the two-creator or two-annihilator terms. The latter have coefficient $-E_p^2+{\mathbf{p}}^2+m^2=0$. The mixed terms giveThe constant $E_0$ is the divergent zero-point energy; a finite box and a momentum cutoff make its meaning explicit. Normal ordering sets the free vacuum energy to zero and leaves all commutators unchanged. Directly applying the mode commutators to the mixed expression yieldsChoose the Fock vacuum by $a(p)|0⟩=0$. Each creation operator adds a boson of energy $E_p$ and four-momentum $p$, while each annihilation operator removes one. Products of commuting creation operators give bosonic statistics from commuting creation operators and unrestricted occupation numbers. The real scalar field has one spin-zero species, identical to its antiparticle. Its one-particle states obey $⟨q|p⟩=(2\pi {)}^{3}2E_p{\delta }^{(3)}(\mathbf{p}-\mathbf{q})$, precisely the relativistic normalization of a one-particle state.

For the Feynman propagator, put $z=x-y$ and contract the two fields in the Fock vacuum. Only $a{a}^{†}$ survives, giving the Wightman functionThe stipulated time-ordered product convention is $i{\Delta }_F(z)=\theta (z^0)W(z)+\theta (-z^0)W(-z)$. In a contour integral over $p^0$, the Feynman i-epsilon prescription places the positive-energy pole just below the real axis and the negative-energy pole just above it. For $z^0>0$ close below, clockwise, obtaining $-i{e}^{-i{E}_p{z}^0}/(2E_p)$; for $z^0<0$ close above, obtaining $-i{e}^{i{E}_p{z}^0}/(2E_p)$. Changing $\mathbf{p}\mapsto -\mathbf{p}$ in the second contribution therefore provesActing with $\square +m^2$ multiplies the integrand by $-(p^2-m^2)$. The remaining factor tends to $-1$ as a distribution, so Fourier inversion givesThe sign also follows from the derivative jump of a free scalar time-ordered two-point function: the first time derivative of $i{\Delta }_F$ jumps by $⟨[\dot{\varphi },\varphi ]⟩=-i{\delta }^{(3)}$, so that of ${\Delta }_F$ jumps by $-{\delta }^{(3)}$.

For the complex scalar field, the canonical momenta are $\pi ={\dot{\varphi }}^{†}$ and ${\pi }^{†}=\dot{\varphi }$. Split $H=H_0+H_I$. The interaction picture is obtained from the Schrödinger picture by $|{\Psi }_I(t)⟩=e^{i{H}_{0}t}|{\Psi }_S(t)⟩$ and $O_I(t)=e^{i{H}_{0}t}{O}_S{e}^{-i{H}_{0}t}$, choosing a common time origin. The fields therefore obey the free Klein-Gordon equation, while the states evolve through $H_I(t)$. The canonical quantization of a complex scalar field givesThe adjoint expansion contains $a^{†}$ and $b$. Particle and antiparticle modes are independent; their nonzero commutators areAll cross-species commutators, and all pairs of creation operators or of annihilation operators, vanish. These formulas reproduce $[\varphi (\mathbf{x}),\pi (\mathbf{y})]=[{\varphi }^{†}(\mathbf{x}),{\pi }^{†}(\mathbf{y})]=i{\delta }^{(3)}(\mathbf{x}-\mathbf{y})$ and the remaining vanishing equal-time commutators.

There are no derivative interactions, so the interaction Hamiltonian is $H_I(t)=-\int d^{3}x{\mathcal{L}}_I(x)$. Differentiating the interaction picture state gives $i{\partial }_t|{\Psi }_I⟩=H_I(t)|{\Psi }_I⟩$. Its time-evolution operator satisfiesIteration gives ordered integration regions $t_1>\cdots >t_n$. Each is $1/n!$ of the full region with a time-ordered product, yielding the Dyson seriesWith the usual asymptotic scattering prescription, taking $t_0\to -\infty$ and $t\to +\infty$ provesTime ordering is essential because different interaction Hamiltonians need not commute.

At first order, use the connected tree scattering amplitude, equivalently the normal-ordered quartic vertex with the vacuum and one-particle mass contributions removed. This qualification matters if the local product is interpreted literally without normal ordering: single-vertex tadpole diagrams and vacuum diagrams are not the requested connected two-particle amplitude. The complex scalar quartic contact vertex is obtained fromIn a fully connected matrix element, an incoming particle and outgoing antiparticle attach to the two $\varphi$ factors; an outgoing particle and incoming antiparticle attach to the two ${\varphi }^{†}$ factors. Each pair has two assignments, giving $2!2!=4$. The external relativistic normalization of a one-particle state cancels each mode measure: for example $[\varphi (x),a^{†}(p_1)]=e^{-i{p}_{1}x}$ and $[b(q_2),\varphi (x)]=e^{i{q}_{2}x}$. Consequently the connected integrand is $4e^{-i(p_1+q_1-p_2-q_2)\cdot x}$, andThus the invariant connected amplitude isThe Dirac delta function expresses four-momentum conservation.

For the identity contribution, commute $a(p_2)$ through $a^{†}(p_1)$ and independently $b(q_2)$ through $b^{†}(q_1)$; all terms leaving a creation operator against the left Fock vacuum or an annihilation operator against the right Fock vacuum vanish. HenceThere is no exchange term between the two distinct particle and antiparticle species.

Use units $\hslash =c=1$ and the Minkowski metric $g_{\mu \nu }=\mathrm{diag}(1,-1,-1,-1)$, so $p\cdot x=E_{p}t-\mathbf{p}\cdot \mathbf{x}$. The canonical momentum of the real scalar field is $\pi =\dot{\varphi }$, and the Hamiltonian operator isCanonical quantization of a real scalar field promotes $\varphi$ and $\pi$ to operator-valued distributions satisfying the equal-time canonical commutation relationProducts and operator commutators can first be interpreted after spatial smearing. An additive vacuum constant in $H$ does not affect the following equations. In the Heisenberg picture, $\dot{O}=i[H,O]$. Applying the canonical commutation relation to the quadratic Hamiltonian operator, and integrating the gradient term by parts, givesThus the Klein-Gordon equation is an operator equation. The spatial Fourier transform reduces it to ${\ddot{\varphi }}_{\mathbf{p}}+E_p^2{\varphi }_{\mathbf{p}}=0$, with $E_p=\sqrt{{\mathbf{p}}^2+m^2}$. Its two frequency branches, together with the Hermitian adjoint condition ${\varphi }^{†}=\varphi$, give the mode expansion of a free fieldThe measure $d\mu (p)$ is Lorentz invariant; its normalization fixes that of the creation and annihilation operators rather than imposing any extra physical assumption.

For invariant-normalized scalar mode extraction, take the Klein-Gordon inner product of $f_p$ with the field. The positive-frequency contribution has coefficient $E_p+E_q$ and spatial integral $(2\pi {)}^3{\delta }^3(\mathbf{p}-\mathbf{q})$. The negative-frequency contribution has coefficient $E_p-E_q$ and spatial integral $(2\pi {)}^3{\delta }^3(\mathbf{p}+\mathbf{q})$, so it vanishes because $E_{-p}=E_p$. ConsequentlyTaking the Hermitian adjoint, with the order of the scalar factors immaterial, yieldsEquivalently $a(\mathbf{p})=\int d^{3}x{f}_p^{\ast }(E_p\varphi +i\pi )$ and $a^{†}(\mathbf{q})=\int d^{3}y{f}_q(E_q\varphi -i\pi )$. At a common time their operator commutator therefore isThe same calculation gives $[a(\mathbf{p}),a(\mathbf{q})]=[a^{†}(\mathbf{p}),a^{†}(\mathbf{q})]=0$: the surviving factor is an energy difference supported at opposite spatial momenta. These are the bosonic canonical commutation relations in relativistic normalization of a one-particle state.

Choose the Fock vacuum by $a(\mathbf{p})|0⟩=0$ and $⟨0|0⟩=1$. Only the annihilator-creator product contributes to the Wightman function, givingUsing time ordering and the reverse product for $y^0>x^0$, the Feynman propagator, with the convention $D_F=i{\Delta }_F$ in this calculation, isIn particular the denominator in the spatial measure is $2E_p$ in both terms.

To verify the four-dimensional Fourier transform representation, let $\tau =x^0-y^0$ and integrate the energy variable first:The Feynman i-epsilon prescription puts the positive-energy pole at $E_p-i0$ and the negative-energy pole at $-E_p+i0$. For $\tau >0$, the contour integral closes in the lower half-plane with clockwise orientation. The residue theorem multiplies the residue $i{e}^{-i{E}_p\tau }/(2E_p)$ by $-i$, giving $e^{-i{E}_p\tau }/(2E_p)$. For $\tau <0$, it closes counterclockwise above: multiplying the residue $-i{e}^{i{E}_p\tau }/(2E_p)$ by $i$ gives $e^{i{E}_p\tau }/(2E_p)$. Thus $I(\tau )=e^{-i{E}_p|\tau |}/(2E_p)$. After inserting the spatial exponential, reversing $\mathbf{p}$ in the negative-time term gives exactly the time ordering expression above. HenceThis equality is understood as a distribution limit; the same prescription gives $(\square +m^2)D_F(x-y)=-i{\delta }^4(x-y)$.

Use $g_{\mu \nu }=\mathrm{diag}(1,-1,-1,-1)$ throughout. Vary the Maxwell action with respect to the electromagnetic four-potential. Antisymmetry of the electromagnetic field tensor gives $\delta \mathcal{L}=-F^{\mu \nu }{\partial }_{\mu }\delta A_{\nu }$. After integration by parts, the Euler-Lagrange field equation isA gauge transformation $A_{\mu }\mapsto A_{\mu }+{\partial }_{\mu }\chi$ leaves $F_{\mu \nu }$ unchanged because partial derivatives commute. It therefore leaves the Maxwell action and observable electromagnetic fields unchanged: different potentials represent the same physical field. This redundancy matters for canonical quantization: before gauge fixing, the momentum conjugate to $A_0$ vanishes and the four potential components cannot be treated as four independent physical oscillators.

Choose the Lorenz gauge $D={\partial }_{\mu }{A}^{\mu }=0$, attainable by solving $\square \chi =-D$ with suitable boundary data. The Euler-Lagrange field equation then reduces toResidual Lorenz gauge symmetry consists of transformations with $\square \chi =0$. The gauge condition and this residual redundancy ultimately leave two transverse polarizations of a free photon.

For the specified kinetic density ${\mathcal{L}}_C=-\frac{1}{2}{\partial }_{\mu }{A}_{\nu }{\partial }^{\mu }{A}^{\nu }$, one has $\partial {\mathcal{L}}_C/\partial ({\partial }_{\mu }{A}_{\nu })=-{\partial }^{\mu }{A}^{\nu }$. Its Euler-Lagrange field equation is therefore $-\square A^{\nu }=0$. This density is the Feynman-gauge Maxwell kinetic density after a boundary-term subtraction, sinceThe divergence follows by expanding both sides and commuting the second derivatives. Thus the wave equation follows from a Feynman gauge action; the additional physical-state condition will implement the Lorenz gauge. One must not impose $D=0$ inside the original action before varying it.

Take the covariant components $A_{\nu }$ as canonical coordinates. The canonical momentum computed from ${\mathcal{L}}_C$ isThe equal-time canonical Poisson brackets are $\{A_{\mu }(t,\mathbf{x}),{\Pi }^{\nu }(t,\mathbf{y})\}={\delta }_{\mu }{}^{\nu }{\delta }^3(\mathbf{x}-\mathbf{y})$, with coordinate-coordinate and momentum-momentum brackets zero. Applying canonical quantization givesIn particular $[A_{\mu },{\dot{A}}_{\nu }]=-i{g}_{\mu \nu }{\delta }^3$. The negative temporal sign is the source of the indefinite state-space norm in covariant photon quantization.
