Past exam of the physics 2 paper of the University of Oxford / 2019 / 9 / b

The electric dipole moment is $\mathbf{p}=qa\hat{\mathbf{y}}$. Write $\theta$ for the angle measured from $+y$, with $\hat{\mathbf{\theta }}$ pointing toward increasing $\theta$. The exact electric potential isFor $r\gg a$, expand the reciprocals to first order in $a/r$. Their common $1/r$ terms cancel, giving the electric dipole approximationThe radial electric field follows from $E_r=-\partial \varphi /\partial r$, and the tangential electric field from $E_{\theta }=-(1/r)\partial \varphi /\partial \theta$. The omitted terms are of relative order $a^2/r^2$ away from zeros of a component. Multiplying by the test electric charge gives the force componentsThe electric field lines emerge from the positive electric charge and terminate on the negative electric charge. They are mirror-symmetric about the electric dipole axis and bow out across its equatorial plane. In the point-electric dipole limit their meridional curves obey $dr/(rd\theta )=E_r/E_{\theta }=2\cot \theta$, hence $r=C{\sin }^2\theta$.
