Axisymmetric stagnation strain Created 2026-10-25 Updated 2026-11-05
A regular axisymmetric irrotational flow near a stagnation point on an impermeable tangent plane has equal tangential strain rates. The incompressibility condition forces the normal rate to be their negative double. Thus the leading velocity potential has the displayed quadratic form. Its streamline invariants are the azimuth and ; for incoming flow from positive , .
Bernoulli's principle 2026-10-14
The Bernoulli principle relates pressure, kinetic energy per unit volume and Newtonian gravitational potential along a streamline of steady flow with inviscid flow. For constant mass density, the Bernoulli equation gives constant along that streamline. Constancy across different streamlines requires further hypotheses, such as irrotational flow.
Precisely, suppose a fluid of constant positive mass density obeys the Euler equations for an inviscid fluid, its velocity field and pressure are steady, and the body force per unit mass is . ThenEvery term has units of energy per unit mass. For a uniform gravitational field, Newtonian gravitational potential is , up to an additive constant. The pressure term represents work by surrounding fluid, so acceleration can exchange pressure work with kinetic energy. Dotting the steady Euler equations with gives the displayed directional derivative: this is why constancy follows a streamline. [ref]
https://www.damtp.cam.ac.uk/user/mem2/FLUIDS-IB/dyn.pdf. Cambridge, Fluid Dynamics IB, Dynamics, section 2.4
Continue the horizontal water constriction example from incompressible flow. Assume negligible viscous losses, steady flow and approximately uniform flow at both measurement sections, so the streamline speeds there equal the mean speeds and . Equal height cancels the Newtonian gravitational potential terms. The ideal pressure drop isThis is the Venturi effect in its ideal limit: the gain in kinetic energy density is supplied by pressure work. Cambridge's treatment uses this relation to connect a measured pressure difference to volumetric flow rate. [ref]
https://www.damtp.cam.ac.uk/user/mem2/FLUIDS-IB/dyn.pdf. Cambridge, Fluid Dynamics IB, Dynamics, section 2.5
The result is conditional, rather than a prediction of the actual viscous pipe. Mass conservation fixes and the ratio of mean speeds even with viscosity, but nonuniform velocity profiles require an integrated energy balance, and wall friction dissipates mechanical energy. A pump would supply additional work. In particular, constant mean speed in a straight pipe does not imply constant pressure: Poiseuille flow needs a continuing pressure gradient to overcome viscosity. [ref]
https://uclnatsci.github.io/2021/Electromagnetism-Fluids-and-Waves/fluids/bernoulli.html. UCL, Bernoulli's equation, assumptions and boundary limitations
Blasius force theorem 2026-10-25
For a steady two-dimensional incompressible flow and irrotational flow around an impermeable body, the displayed contour formula gives the force on the body per unit span. Here is the complex velocity, is the constant mass density, and runs counterclockwise around the body, excluding other fluid singularities. To verify the sign, Bernoulli's principle gives . On a counterclockwise boundary, the complex pressure force is . Tangency gives , and therefore . Integrating removes the constant term and gives the formula. The theorem is named after Heinrich Blasius.
Blasius moment theorem 2026-10-31
For steady incompressible flow and irrotational flow of constant mass density, with no body force, this formula gives the hydrodynamic torque about the origin per unit span on an impermeable body. Orient its boundary counterclockwise, and let positive torque be counterclockwise. The proof uses , the Bernoulli equation , and the tangency identity . The real part of the constant-pressure term vanishes because . The full complex integral of need not vanish.
Corner sink in a semi-infinite channel Created 2026-10-14 Updated 2026-11-05
For unit channel width, incompressible flow towards a corner withdrawal point has on the lower wall and on the upper and left walls, with far downstream. For irrotational flow, separation of variables gives the displayed harmonic correction: the Fourier sine coefficients of are . Near the corner, and radial velocity is , whose integrated inward flux across a quarter-circle is .
D'Alembert's paradox 2026-10-13
Ideal steady flow with incompressible flow, inviscid flow and irrotational flow can predict zero drag on a body that has nonzero drag in a real fluid. The zero-circulation cylinder pressure coefficient distribution gives an explicit cancellation example; viscosity and flow separation are absent from that model.
Dispersion relation Created 2026-09-24 Updated 2026-10-14
A dispersion relation specifies which angular frequencies and wavevectors a linear wave model admits. Fix the plane wave conventionHere is a constant complex amplitude, is the wavevector, and is the angular frequency. Substitution into a constant-coefficient linear partial differential equation replaces by and by , turning the wave problem into an algebraic condition. A system can have several roots; means one chosen branch, rather than a promise that the full dispersion relation is single-valued. For real , means temporal growth in this convention, while means damping. The real-branch discussion of phase velocity and group velocity below assumes negligible loss.
For the one-dimensional wave equation , the dispersion relation is . The branch carries right-moving travelling waves for ; both its phase velocity and group velocity are . One may instead use the positive-angular frequency branch , with right-moving components at and left-moving components at . A real wave pairs each with ; that conjugate pair represents the same travelling pattern. Branch and sign choices therefore matter when interpreting a dispersion diagram.
A particularly tangible dispersive example is a small-amplitude surface gravity wave on still water of uniform depth . Neglect surface tension and viscosity, assume incompressible flow and irrotational flow, and impose a flat impermeable bottom. With and positive angular frequency,Here is gravitational acceleration and is the hyperbolic tangent. Deep water means : and longer wavelengths have larger phase speed. Shallow water means : , an approximately nondispersive wave. Thus depth relative to wavelength, rather than depth alone, determines whether crests and wave packets travel together.[ref]
The dispersion diagram below also includes the ideal deep-water capillary wave limit , where is surface tension and is mass density. This limit requires the surface tension restoring term to dominate gravity; it reverses the trend of the surface gravity wave, giving larger phase speed at shorter wavelength. The combined gravity-capillary wave has .[ref]
Analytical dispersion diagrams: origin-to-point slope gives phase velocity, tangent slope gives group velocity
. Details. The curves use dimensionless normalizations chosen separately for each model; they are analytical diagrams, not experimental data. Their beauty is that a single dispersion relation encodes several observable behaviours: its value gives the angular frequency, its origin-to-point slope gives the one-dimensional phase velocity, its tangent slope gives the group velocity, and variation of that tangent slope predicts distortion of a wave packet. A straight line through the origin describes a nondispersive wave; an affine branch with has constant group velocity but phase velocity , so those properties must be distinguished.
Dynamic pressure 2026-10-14
Dynamic pressure is the bulk kinetic energy per unit volume associated with fluid motion at speed in a specified reference frame:Here is mass density. The word "pressure" identifies its units and its use as a pressure scale; is not an extra isotropic stress to add to the local static pressure in every surface traction. A stationary fluid can have large static pressure with . Conversely, knowing and fixes without fixing static pressure. The definition remains useful in viscous fluid flow and compressible flow, even when the simplest Bernoulli equation is inapplicable. [ref]
For stipulated mass density and reference speed , . At with the same mass density, . This quadratic scaling makes dynamic pressure a useful normalization for the lift coefficient, drag coefficient and pressure coefficient; it predicts four times a particular force only if its corresponding coefficient remains unchanged.
The connection with stagnation pressure requires hypotheses. For steady flow, constant mass density, inviscid flow, and gravity as the only body force, the Bernoulli equation gives, along one streamline,Here is static pressure, is gravitational acceleration, and is height. Bring that flow to rest without losses at the same height and the limiting static pressure is the stagnation pressure :There must be no intervening pump supplying work or other energy input. Constancy along one streamline does not assert equal on all streamlines; irrotational flow in a connected region supplies that additional conclusion. Changing height requires retaining . In compressible flow the stopping pressure difference generally differs from , and viscous dissipation can reduce recovered stagnation pressure. [ref]
A Pitot-static tube turns this relation into a measurement: its upstream-facing opening senses stagnation pressure, while separate side openings sample static pressure. Connect these to the positive and negative ports of a differential pressure transducer or manometer. Under the hypotheses above, the measured difference givesThus the stipulated and imply , not an independently measured speed. Align the probe with the incoming flow and keep its passages clear: blockage and pinched tubing invalidate the comparison. At very low speed, the difference can be smaller than instrument error; at high Mach number, compressibility and possibly a shock wave require a different reduction. [ref]
A useful control is differential-pressure calibration. For a digital manometer, zeroing establishes the reading at equal port pressures; it does not establish the gain away from zero. The manufacturer's Series 475 Handheld Digital Manometer: Specifications - Installation and Operating Instructions by Dwyer Instruments, Inc. directs the user to vent both ports to the atmosphere before zeroing. Its stated accuracy is a fraction of full scale, not of the reading, and depends on instrument temperature. Select a suitable range and record the instrument variant and units; the manual covers several ranges.[ref]
Series 475 Handheld Digital Manometer: Specifications - Installation and Operating Instructions by Dwyer Instruments, Inc.. p. 1: Specifications, Model Chart and ZERO instructions
An independent physical check can use a liquid-column manometer: apply a stable pressure difference to both instruments and compare the digital reading with the hydrostatic pressure inferred from the vertical level difference. For equal-height connections carrying a gas of mass density above a manometric liquid of mass density ,This follows by balancing hydrostatic pressure down and up the two connected columns. Use vertical height, even if a tube is inclined. Known mass densities, measured height and gravitational acceleration set the comparison scale. Check several differences across the working range and reverse the port connections to check the sign. This is a proposed independent check, not a claim that the cited teaching experiment performed a full instrument calibration. Recheck zero after reconnecting the sealed tubing; a zero adjustment alone cannot detect a blocked passage or an incorrect scale.
Gravity-capillary wave Created 2026-10-14 Updated 2026-10-20
A gravity-capillary wave has restoring contributions from both gravity and surface tension. Consider an initially resting, horizontally unbounded liquid layer of constant depth , with uniform mass density , incompressible flow, inviscid flow and irrotational flow. The upper gas exerts constant pressure and has negligible inertia. Assume a clean interface with constant surface tension : no surfactant stresses, imposed current or wind. The wave amplitude must satisfy and , so linearized boundary conditions apply. Deep water means , rather than a particular depth in metres. [ref]
https://www.ocw.mit.edu/courses/18-354j-nonlinear-dynamics-ii-continuum-systems-spring-2015/6163837c5efa5d6ed969e535ec8f890c_MIT18_354JS15_lectureNotes.pdf. Brenner, Peacock, Stocker, Reis and Dunkel, MIT Nonlinear Dynamics II, §23.1, pp. 105–106
Let be the undisturbed free surface, with liquid below it. Potential flow gives a velocity potential with , and incompressible flow gives the Laplace equation. The linearized kinematic boundary condition for a free-surface graph and the Unsteady Bernoulli equation, including gravity and the Young–Laplace equation, giveHere is the interface displacement; the signed small-slope pressure jump is . A wave crest has , so its capillary pressure is positive. Choose a right-travelling Fourier mode of positive wavenumber and angular frequency :The factor decays into the deep liquid, satisfies the Laplace equation, and makes at . Substituting in the dynamic boundary condition leavesThis derivation displays the two restoring contributions with the same sign. Dimensional analysis also checks the result: has units , so both and have units . [ref]
https://www.ocw.mit.edu/courses/18-354j-nonlinear-dynamics-ii-continuum-systems-spring-2015/6163837c5efa5d6ed969e535ec8f890c_MIT18_354JS15_lectureNotes.pdf. MIT Nonlinear Dynamics II, §23.1, equations (547)–(551): boundary conditions and dispersion
At finite depth, a flat impermeable bottom at requires . Replacing by the normalized vertical factor makes the surface ratio . Eliminating the mode amplitudes then givesThus the same model supplies its own depth check: use the deep-water formula only when is sufficiently close to one for the required accuracy. For example, reduces by about relative to deep water, while reduces it by about . These percentages are calculations from this factor. [ref]
In deep water the phase velocity magnitude follows a wave crest, while the group velocity magnitude follows the wave envelope of a narrow wave packet. Differentiating the positive-frequency dispersion relation givesFor , the surface gravity wave limit has . For , the deep-water capillary-wave dispersion relation has : a wave crest slips backward relative to the faster wave envelope, even while both advance. Neither speed is the oscillating fluid element's own velocity. [ref]
There is a particularly neat coincidence at the crossover. Differentiate : its unique minimum is at , exactly where the restoring terms are equal. ThereforeFor the stipulated parameters in capillary length, the minimum is . At , direct substitution gives , and . This short wavelength is capillary dominated, but its group velocity is still slightly below the pure-capillary ratio because gravity has not vanished.
Irrotational flow Created 2026-09-24 Updated 2026-10-14
Use irrotational flow to identify where a velocity potential can describe the velocity field locally. An irrotational flow has throughout the fluid region. For a continuously differentiable velocity field, the Poincaré lemma supplies a velocity potential on sufficiently small neighborhoods. A global single-valued velocity potential requires zero circulation around every closed curve; a simply connected domain is a sufficient domain assumption.
The potential line vortex is an irrotational flow on the punctured plane, or on an annulus with , even though its pathlines are circular. Every sufficiently small loop bounding a disk in that fluid has zero circulation, by Stokes theorem. A loop winding once counterclockwise around the excluded origin has circulation . Thus local irrotational flow and nonzero circulation around a hole are compatible: the enclosing disk passes outside the domain of the velocity field.
An irrotational flow is a kinematic condition on a velocity field, independent of whether a particular model neglects viscosity or assumes incompressible flow. Adding incompressible flow makes the local velocity potential satisfy the Laplace equation. This reduces the number of unknowns and makes potential flow a powerful starting point for flow around bodies and for gravity waves. [ref]
Linear homentropic acoustic equations Created 2026-09-29 Updated 2026-10-06
For perturbations about a uniform fluid of density , the linearized continuity equation, momentum equation, and homentropic pressure perturbation relation areFor irrotational flow , they imply and .
Line source Created 2026-10-25 Updated 2026-11-05
In a planar incompressible flow, a line source injects volume flux per unit length perpendicular to the plane. Its radial velocity is , since integrating the outward velocity around a circle gives . Its complex potential of a two-dimensional potential flow is and its complex velocity is . Here means outward flow; a line sink has negative . Away from , this is an irrotational flow as well as an incompressible flow.
For a steady inviscid barotropic fluid in a conservative gravitational potential, define . Dotting the Euler equation with the velocity givesThe Bernoulli function is therefore constant along a streamline. It balances kinetic energy, pressure work or enthalpy, and gravitational potential energy per unit mass. Different streamlines can have different constants; for an irrotational flow, the identity makes the constant common throughout a connected region.
For an incompressible fluid, up to a constant, giving . For a constant-entropy perfect-gas streamline, . Together with mass conservation, this explains conversion of enthalpy into kinetic energy in a nozzle and the need to include gravity in an escaping wind. Viscous losses, heating and entropy production require their corresponding energy balance. Across an adiabatic shock the total stagnation enthalpy can still be conserved, but the upstream isentropic pressure-density law cannot simply be continued through the entropy jump.
For planar incompressible flow, . Locally this permits a streamfunction with , , because equality of the mixed derivatives enforces incompressibility. The remaining component of the curl is , so irrotational flow requires Laplace's equation for .
Put . The sinusoidal contribution to the supplied streamfunction has and ; the linear term is also harmonic. HenceAs , these approach the specified uniform flow, .
The impermeability kinematic boundary condition is on , equivalently is constant on the wall. For , evaluating the perturbed velocities at gives to first order. The residual is of order . Equivalently . The surface velocity isThe first expression is the supplied approximate field evaluated exactly at the wall; its accuracy as a wall-flow solution is still only first order in .
Take positive circulation to mean counterclockwise in the diagram, with right and up. The upper surface is then traversed right to left. To first order in ,Thus the bound circulation is clockwise. Any exterior contour enclosing the hydrofoil has the same circulation in an irrotational flow; a globally completed two-dimensional flow must contain a circulation component decaying as at large distance. The simple local upper/lower velocity prescription cannot describe the entire exterior. For a start from rest, Kelvin's circulation theorem requires compensating shed vorticity, represented by a starting vortex in a physical wake.
Numerically,If the question's fluid force includes buoyancy, and the total upward fluid force is about , using . Weight of the hydrofoil is not specified and is not part of this fluid force. The motion-induced lift also agrees with the Kutta–Joukowski theorem, in this orientation.
The chord-based Reynolds number isAt this large Reynolds number, smooth laminar flow over the whole body is unlikely in ordinary conditions; wall layers may undergo transition and separate. A thin-layer inviscid flow approximation outside them can remain useful, but does not justify globally laminar flow.
An irrotational flow satisfies . On a simply connected region, or locally on any small regular region, this gives a velocity potential with . The incompressibility condition is , soThus the potential is a harmonic function. The locality qualification matters: a curl-free circulation around an excluded vortex core need not admit a globally single-valued potential. No such circulation is needed for the sphere flow below.
Choose the planar streamfunction convention , . For an irrotational flow, a velocity potential gives . ThusThe streamfunction enforces incompressibility, since . Conversely, incompressibility permits a local streamfunction, while zero curl permits a local velocity potential. These are the Cauchy-Riemann equations for the complex potential of a two-dimensional potential flow .
The gradients of the two functions satisfyEach gradient is normal to its regular level curves. Therefore regular curves of constant velocity potential and constant streamfunction meet orthogonally. At a stagnation point, both gradients vanish and this tangent-direction argument needs a limiting interpretation. The conclusion concerns regular portions of the two families of curves.
The total velocity fields on the two sides areEach base flow is divergence-free. Incompressibility therefore makes both disturbance velocity potentials satisfy the Laplace equation:At the fixed horizontal walls, impermeability requires zero vertical velocity:The discontinuity in tangential base velocity at the interface is a vortex sheet. The assumption of irrotational flow is understood separately in each open fluid region; it cannot hold distributionally across that sheet when .
Substitute the given Stokes streamfunction representation into the divergence in spherical coordinates. The mixed derivatives cancel:Thus incompressibility is automatic for a smooth Stokes streamfunction. Since this is an axisymmetric flow with no azimuthal velocity, the only possibly nonzero component of its vorticity isDefine the differential operator in the Stokes streamfunction equation for irrotational flowThe stated equation is , and thereforeThe irrotational flow has a velocity potential locally, and globally on a regular simply connected domain. Regularity of the physical velocity field supplies the limiting interpretation on the polar axis, where the coordinate expressions contain in the denominator.
Put and define the image term . The key step is to verify that inversion preserves the Stokes streamfunction equation for irrotational flow. Direct differentiation giveswhere the quantities on the right are evaluated at . HenceBy linearity, obeys the same equation and describes an incompressible flow and an irrotational flow wherever the original exterior flow is regular.
On the sphere, and the two terms cancel identically:Thus the sphere is a stream surface and satisfies the no-penetration boundary condition. Tangential slip is allowed in this potential flow model. For every finite , the image argument satisfies , where has no singularities. The prefactor is regular there. Therefore the construction creates no new finite exterior singularities; any original exterior singularities remain those of the prescribed incident flow. This is the sphere theorem for a Stokes streamfunction.
For the far-field claim, the stated bound givesOne must compare velocities, rather than require the correction to the Stokes streamfunction to tend to zero. Smoothness at the original origin, together with , gives and there. Thus and , and the correction hasThese estimates hold away from the coordinate poles, with the regular-axis limits supplied by the original smooth physical flow. ConsequentlyThe far-field velocity field is unchanged. For a fully smooth incident velocity field at the origin, the usual regular expansion is stronger and makes the sphere disturbance decay as .
