Atmospheric pressure Created 2026-10-14 Updated 2026-10-18
Atmospheric pressure often provides the reference for a gauge pressure measurement: . The absolute pressure is measured relative to an ideal vacuum, whereas zero gauge pressure means equality to the chosen reference. The actual atmospheric pressure can vary; it must be specified when converting between these descriptions. [ref].
A laboratory gravity gradiometry experiment used two vertically separated clouds of chemical atoms in vacuum, launched into free fall. Shared laser beams applied three pulses (), splitting and recombining matter waves. Balanced photodiodes measured probe-light absorption to infer internal-state populations; scanning the last pulse's wave phase produced an interference fringe.[ref]
The difference of fringe wave phases obeys , with effective wave vector and pulse spacing : shared reference motion cancels, leaving differential gravitational acceleration. Eight lead bricks, each approximately , were placed symmetrically around the lower chamber, about from the fountain apex. The measured signal was , versus a calculated , where denotes terrestrial gravitational acceleration.[ref]
Controls deliberately shook the shared reference reflector and compared actively isolated and unisolated operation. Tilting tests exposed sensitivity to Coriolis acceleration and centrifugal acceleration. Thus shared translation is rejectable, while rotation and finite measurement uncertainty remain limitations. The brick signal detects spatially varying gravity; it does not establish a precision value of the gravitational constant.[ref]
Beam divergence 2026-10-14
Beam divergence describes the angular spread of a beam away from its optical axis; specify the radius convention and whether the quoted angle is a half-angle or full angle. For the fundamental Gaussian beam in vacuum, the far-field light intensity radius obeys
Here is the small-angle half-angle in radians under the paraxial approximation; the full angle is . The geometric asymptote has angle , approximated by in this regime. Other beam profiles need their own beam divergence definitions and propagation laws.
Biot-Savart law Created 2026-09-24 Updated 2026-10-18
For a steady current density , the magnetic field is
The Biot-Savart law adds magnetic field contributions from a specified electric current distribution. The vectors and locate source and observer; points toward the observer. Here is vacuum permeability. For a thin wire carrying electric current , the volume integral becomes a line integral:
Here follows positive conventional current; is the unit vector toward the observer. With fixed path orientation, reversing the electric current replaces by . The cross product and right-hand rule fix the direction. Reversing the source-to-observer displacement would give the wrong sign.[ref]
The setting is magnetostatics: time-independent current density and charge density, in vacuum or with the vacuum approximation for air. Electric charge conservation then gives . A finite segment is part of a complete electrical circuit; its endpoints cannot continuously accumulate electric charge in a steady state. The instantaneous integral above does not describe switching transients or electromagnetic radiation. In magnetic matter, specify the total current density, including magnetization current, rather than automatically replacing by an arbitrary magnetic permeability.[ref]
The superposition principle makes the Biot-Savart law useful even when the complete electrical circuit lacks the symmetry needed to evaluate Ampère's circuital law directly. Integrate a straight piece, a curved piece, and the return path separately, then add their magnetic fields as vectors. The beauty is that a local oriented current element produces both the circulating magnetic field of a finite straight wire and the reinforcing on-axis magnetic field of a circular current loop.
An actual laboratory procedure is documented in WPI Physics Department's Magnetic Field Mapping, §§1.2–1.2.3 and the single-coil checklist on p. 9. Preparation locates the active area of a Hall effect sensor using a small magnet. A field meter reads the component normal to that area. The wire apparatus is a wall-mounted square loop selectable between one and five conductors. The coil connects to a power supply and ammeter; its diameter and turn count are recorded. Align the sensor and scan distance. The control is a current-off background reading at each position, subtracted from the current-on reading. The inference compares corrected magnetic field with position and the predicted geometry dependence. Active-area displacement, sensor tilt, background variation, and finite coil width limit that comparison. These are instructions, not reported measurements.[ref]
A further proposed control is to reverse at fixed sensor position and orientation. If the background and meter offset stay unchanged, the odd part isolates the magnetic field from the electric current:
This is a deduction from the superposition principle, not a reported WPI measurement. The measured component, sensor position, and complete return path must still match the model.
Boyle's law 2026-10-14
Boyle's law states that a fixed amount of substance of an ideal gas at constant absolute thermodynamic temperature has constant product of absolute pressure and total volume:
Here is measured relative to a vacuum, not relative to the surrounding atmospheric pressure. Halving the volume doubles the absolute pressure; doubling the volume halves it. A real gas approximately follows Boyle's law when it is sufficiently dilute and far from a phase transition.[ref]
For an original calculated example, suppose a sealed gas sample has and . After isothermal compression to ,
Both states have , since . The volume ratio is dimensionless, so using the same volume units in numerator and denominator leaves the pressure in kilopascals. Although has units of energy, its value is not the compression work: isothermal ideal-gas work involves an integral along the path.
Figure 1.
Boyle's law: a pressure-volume curve becomes a straight line against reciprocal volume
. Details.
The blue curves show calculated ideal gas states, not measurements. The left panel is a branch of a hyperbola; the right panel plots exactly the same absolute pressures against . The dashed line uses gauge pressure with a stipulated constant atmospheric pressure of . Its displaced intercept explains why absolute pressure in Boyle's law matters.
A short derivation starts from the ideal gas law, . Fixing the amount of substance and absolute thermodynamic temperature fixes , where is the molar gas constant. The microscopic picture in ideal gas pressure from wall collisions is equally appealing: at fixed temperature, the typical particle kinetic energy stays fixed, while compression increases the number density and wall momentum transfer per unit surface area and time. A larger absolute pressure follows without requiring hotter particles.
The constraints are essential. A leak changes the amount of substance. Rapid compression can raise the temperature before heat transfer restores thermal equilibrium, as in the isothermal gas syringe experiment. Molecular size and interactions in a dense real gas invalidate the ideal gas approximation; the Van der Waals equation describes one such correction. Equal endpoint temperatures allow an endpoint test of Boyle's law, but do not establish that every intervening state lies on an isothermal process.
For fixed mass , mass density satisfies , so it is proportional to absolute pressure. In a dilute bubbly flow, Boyle's law allows bubble volume and its contribution to buoyancy to increase as hydrostatic pressure decreases, provided gas mass is retained, dissolution is negligible, and the temperature stays approximately fixed. Its usefulness is that a simple ratio predicts a substantial size change without tracking individual molecules.
A vacuum ray incident normally on a dielectric moving parallel to its surface becomes oblique in the material rest frame, with . For a transparent nonmagnetic dielectric, the rest-frame Brewster angle satisfies , giving . The reflected electric field is perpendicular to the plane containing the ray and the velocity. A real refractive index is assumed; dispersion makes the condition implicit through the rest-frame frequency, and absorption generally removes exact extinction.
Charged sheet between grounded parallel plates Created 2026-10-18 Updated 2026-10-25
Place an infinite sheet of surface charge density at between grounded conducting planes , in vacuum. Reflection symmetry and Gauss's law give in the two gaps. Integrating the electric field with zero electric potential at the conductors gives . Each facing conducting surface carries induced surface charge density . For , an electron released from rest at a plate reaches the sheet with kinetic energy ; its nonrelativistic speed follows from .
In a phase-invariant vacuum, a correlator with insertions of and of gains the phase . Its invariance for all real forces it to vanish unless . Balanced local interactions and the absence of same-charge free contractions give the same rule order by order in Wick's theorem. A symmetry-breaking vacuum is an essential exception to the vacuum-invariance premise.
For vacuum wavelength endpoints , the corresponding frequency span is . The reciprocal-bandwidth estimate of optical coherence time is , giving . This endpoint conversion is valid even for a broad band, whereas requires a relatively narrow optical spectrum.
For constant spectral density per unit frequency in the band, the normalized first-order optical coherence is . Its first zero occurs at . A different spectral shape or a different contrast criterion changes the numerical optical coherence length; endpoints alone do not define an exact universal value.
Suppose the two input beams share frequency, electromagnetic polarization and overlapping transverse profiles at each output, with stable relative wave phase during the photodetector's averaging interval. For the ideal beam splitter scattering matrix above, expanding the squared complex amplitudes gives
The imaginary part terms describe wave interference. Applying the single-input power split to each input separately and adding the results would discard these terms. Their opposite signs ensure : conservation of energy survives even when one output is dark.
For an original example, let , and . Then and :
Relative input wave phase Output power Output power
At , makes and ; at the dark output swaps. Thus the two inputs can feed all their combined power into one output without gain. At zero relative input wave phase, the splitter's own relative wave phase leaves the contributions in quadrature, so neither output is dark.
Figure 1.
Relative input wave phase redirects the combined power of two coherent beams
. Original ideal-model curves for , and . Output powers are normalized by one input's power ; their sum is always . Markers show the three worked cases. These are calculated curves, not measured data. Details.
For fluctuating fields, average the cross term as . It vanishes for mutually uncorrelated inputs, making the independent power-splitting rule valid for the averaged output. Partial first-order optical coherence reduces it. Orthogonal linear polarizations eliminate the cross term in a polarization-insensitive power readout, and spatial mismatch reduces the overlap. Detector averaging can also erase rapid relative wave phase changes. A fixed relation between two inputs can be prepared by splitting one laser beam and recombining the two arms.
An actual teaching protocol in Michelson Interferometer & Precision Wavelength Measurement — Week 1, University of Colorado Boulder, §§4–6, starts with an ideal-model prediction, then builds a Michelson interferometer using a helium-neon laser, a nonpolarizing beam splitter, adjustable mirrors, a micrometer translation stage and a photodetector. Steering mirrors align beam overlap at near and far planes; far-plane interference fringes refine alignment. Moving the arm mirror changes the returning relative wave phase; detector voltage is watched with a live acquisition display or oscilloscope. The guide compares measured arm powers with 50:50 splitting and asks for a revised field model. It tests electromagnetic polarization dependence, optionally changing one arm with a quarter-wave plate, and estimates noise from repeated readings at fixed mirror position. These controls test whether fringe changes reflect coherent recombination rather than splitter imbalance or misalignment. The guide supplies a protocol, not a numerical dataset. Its detector noise, imperfect overlap and electromagnetic polarization mismatch limit displacement inference.[ref]
Additional background subtraction controls follow from the field model: block both arms to record the detector offset and ambient light, then unblock each arm separately to establish its detected power at fixed gain. With both open, scan the mirror and compare extrema after subtracting that background. Keep the detector below saturation and repeat the scan to check drift. A changing signal alone cannot distinguish source optical coherence from motion or changing overlap. For a vacuum round trip, a mirror displacement changes relative wave phase by ; the useful signal is its modulation after detection, not an optical-frequency oscillation that the detector must resolve.
In 2014, Gabriele Rosi and colleagues used atom interferometry: two rubidium-87 clouds prepared by laser cooling in vacuum, apart, received shared three-pulse Raman transitions spaced by . Fluorescence readout and paired-fringe ellipse fitting yielded differential wave phase. Twenty-four tungsten alloy cylinders, about total, moved between C and F. Cloud subtraction rejected shared vibration; configuration subtraction isolated the source change.[ref]
Figure 1.
Cold-atom measurement: two clouds and two source configurations
. Original conceptual scheme; selected cylinders represent surrounding arrays. Geometry is schematic.[ref] Details.
Calibration used timed flight and light-sheet crossings; mirror tilt compensated Earth rotation. Wave vector reversal rejected unwanted shifts. Modeling included source Newtonian gravitational potential, atom trajectories, cloud distributions and moving supports. Source positioning, mass density variation and cloud geometry limited the reported combined relative standard uncertainty to parts per million.[ref]
To understand the subtraction without reproducing that full analysis, consider an ideal atom interferometer in uniform vertical acceleration during each pulse sequence. Let be its signed effective vertical wave vector component and the pulse spacing. Its acceleration-dependent wave phase is ; labels U and L denote upper and lower clouds. The double difference is then
A background field identical in C and F cancels even if it differs between the two clouds. In a fixed-geometry, linear-response model, write , where is calculated from the source mass density, calibrated pulse sequence and atom trajectories. Thus . Measuring wave phase accurately is one part of the task; calculating accurately is another. The real nonuniform field and finite clouds require the trajectory-dependent analysis described above rather than this uniform-field approximation.
Opening the pinhole increases accepted in-focus and out-of-focus photons; closing it strengthens confocal optical sectioning while discarding some useful in-focus photons too. In the synthetic model, transmits approximately of the collected in-focus emission. At the corresponding peak-normalized signals are about . These are calculated fractions under stated assumptions, not instrument measurements.
An Airy unit conventionally specifies a pinhole diameter equal to the first-zero diameter of the emission Airy disk in that plane. For an ideal circular pupil,
where is the total specimen-to-pinhole magnification, the emission wavelength in vacuum, and the objective numerical aperture. A software setting needs its specified wavelength and relay magnification; it is not a universal micrometre diameter. [ref]
For ideal independent counting, accepted source and background means and give photon shot noise with variance and signal-to-noise ratio in photon counting . Closing a pinhole need not improve that ratio: it depends on how both and change. Increasing exposure or excitation to replace discarded photons can cause bleaching, an irreversible loss of fluorescent emission capacity, or damage. Detection rejection occurs after excitation and therefore does not undo excitation outside the selected depth. Such material can absorb illumination and emit photons even when their emission is omitted from the recorded image.
A contact potential difference is an electrostatic electric potential difference associated with different conducting surfaces brought into electrical equilibrium. Surface condition and different work functions can create a vacuum gap field even when an external voltmeter reads zero. Connecting the metals establishes equilibrium of their electronic chemical potentials including electrostatic energy; it need not equalize the electrostatic electric potential in the gap.
Coulomb potential energy Created 2026-10-14 Updated 2026-10-18
The Coulomb potential energy is the interaction potential energy of two point charges in vacuum. With separation , electric charges , and zero potential energy at infinite separation,
This is mutual interaction energy; it does not include the divergent self-energies of ideal point charges. Unlike electric potential, which has units of volts, has SI units of joules. With charge 1 fixed and positive radial direction away from it, the conservative force in Coulomb's law gives
Thus the potential energy and the inverse-square law for force are two descriptions of the same interaction. [ref].
For , and , using the stipulated approximation ,
At , . Separating the pair from to therefore requires external work if the initial and final kinetic energies agree; the electric force does of work. Separating them all the way to infinity requires . The negative initial potential energy means that the pair lies below the chosen separated reference; it does not mean a negative kinetic energy.
Like-signed electric charges have positive , which decreases as they separate, so their electric force is repulsive. Opposite-signed electric charges have negative , which decreases as they approach, so their electric force is attractive. This attractive interaction supplies the Coulomb potential used in the hydrogen atom; determining its stationary quantum states also requires quantum mechanics. [ref]. Dividing by a nonzero test electric charge gives the source's electric potential . More generally, the electrostatic potential energy of point charges sums each unordered charge pair once. This energy description is useful because work between two separations follows from endpoint values, without integrating a complicated trajectory.
Coulomb's law Created 2026-09-24 Updated 2026-10-14
Coulomb's law gives the mutual electric force between stationary point charges in vacuum. Put electric charges and at and , and define the displacement from charge 1 to charge 2 by , with separation and unit vector . In SI units, the force on charge 2 due to charge 1 is
Here is the vacuum permittivity. The magnitude is . If , the force on charge 2 points away from charge 1; if , it points toward charge 1. Interchanging the charges gives , consistent with Newton's third law in this electrostatic setting. [ref].
For a fully computed example, stipulate , , , and the approximate value . Then
The force is attractive, of magnitude . The source electric field at charge 2 is , pointing away from the positive source. Multiplication by the negative reverses the direction to give the attractive force. This field excludes charge 2's own self-field.
Holding the electric charges fixed while changing the separation from to or gives the normalized inverse-square law values
For the stipulated example, separations , and give magnitudes , and . The diagram computes these ratios and uses one common arrow-length scale for both sign choices.
Figure 1.
Equal and opposite Coulomb force vectors: like charges repel, unlike charges attract, and doubling or tripling separation gives one quarter or one ninth of the force
. Details.
The inverse-square law has a geometric explanation through Gauss's law: a source point charge gives fixed total electric flux through a concentric sphere, whose surface area is . Dividing that flux by the area gives a radial electric field proportional to . This connects a pairwise force calculation to a global conservation-like accounting of field sources. For several stationary point charges, the superposition principle adds the individual electric fields as vectors, and uses all sources except charge itself. The Coulomb potential energy gives an alternative route when the desired quantity is work rather than instantaneous force.
For a source-free plane electromagnetic wave in vacuum, let be its null propagation Lorentz four-vector. In signature , take , , and define the dual electromagnetic field tensor by , . Lower both indices with the Minkowski metric. Direct contraction gives
Both contractions vanish exactly when the transverse plane electromagnetic wave Maxwell equations hold. Being zero covectors, they remain zero in every inertial frame. Thus the transformed spatial wavevector is perpendicular to both transformed fields, even though the separate three-dimensional dot products are not themselves Lorentz scalars for arbitrary fields.
One contraction alone is insufficient without the other Maxwell equations. In particular, adding a magnetic field parallel to leaves unchanged but violates . Conversely the two scalar perpendicularity conditions alone do not impose the required relation between field strengths and directions.
Critical angle for total internal reflection Created 2026-09-29 Updated 2026-10-25
For refractive indices , the critical angle for total internal reflection satisfies . Above it, the transmitted normal wavenumber is imaginary and the transmitted field is an evanescent wave.
The critical angle for total internal reflection is the boundary between outgoing refraction and an evanescent wave, rather than an angle at which the external electric field abruptly disappears. Write and . At the threshold, Snell law for electromagnetic waves has , hence
Here inverse sine selects . For and , and . The threshold is independent of polarization of an electromagnetic wave under the stated assumptions.
A short proof using phase matching at a planar wave interface reveals all three cases at once. Choose a Cartesian coordinate system with boundary , incident medium , and transmitted medium . With vacuum wavenumber , the shared tangential wavevector component is . The dispersion relation in medium two gives
Below , choose the positive real square root for an outgoing plane electromagnetic wave. At , : there is a grazing wave, with zero normal average power but no exponential confinement in . Above , choose with , so the wave amplitude decays into the second half-space.
If , no nongrazing angle of incidence produces this threshold. As from below, ; as that ratio tends to zero, . These limits explain why a larger refractive index contrast permits confinement over a wider range of internal angles.
Cryogenic radiometer Created 2026-10-14 Updated 2026-10-14
A cryogenic radiometer uses low-temperature operation to improve electrical substitution radiometry through particular material and thermal properties. Lower heat capacity of a copper receiver permits a substantial cavity without proportionately slow relaxation; cold shields reduce unwanted thermal radiation, and heater leads with superconductivity can suppress resistive lead heating. These features do not make radiometric absorptance exactly one or abolish optical-electrical heating non-equivalence.[ref]
Cold surroundings matter as much as a cold receiver. In a simplified gray-surface model, net outward thermal radiation is , using emissivity , area , shield temperature and the Stefan-Boltzmann constant . Cold shields reduce the incoming term as well as the receiver's emission; cooling the receiver alone while leaving it exposed to warm surroundings does not remove incoming radiation. An entrance window still provides an optical and thermal path. Vacuum reduces gas-mediated heat transfer, while an intentional radiometer thermal link remains necessary. This model explains specific losses, rather than promising a universal improvement factor or perfect accuracy.
Current-distance test of vacuum tunnelling Created 2026-10-14 Updated 2026-10-20
Tunneling through a controllable vacuum gap by Gerd Binnig and others made barrier width experimentally adjustable. Their apparatus used a pointed electrical conductor opposite a conducting plate, with fine positioning by piezoelectricity. Rubber-tube support and magnetic levitation above a cooled bowl exhibiting superconductivity suppressed vibrations; the junction itself remained near room temperature.[ref]
The readout was electrical resistance versus displacement at a fixed electric potential difference of 60 mV of either polarity. They observed an exponential function dependence spanning four orders of magnitude. Cleaning and better vacuum increased the inferred barrier from approximately 0.6-0.7 eV to 3.2 eV. Reproducible curves and the cleaning response argued against deforming contamination layers; an appropriate slope also helped exclude an ordinary conducting contact. The paper reports residual contamination, electronics-limited range and a jump attributed to release of thermal stress; its curve origins generally do not determine absolute gap widths.[ref]
The ideal tunnel junction model explains the slope. At fixed small electric potential difference, fixed tip geometry and approximately unchanged density of states, take an effective barrier energy above the relevant electron states and approximate the current magnitude by
The coefficient includes the applied electric potential difference, available occupied and empty quantum states, and tip geometry. A single transmission probability is not an electric current: a junction combines contributions from many electron states in both directions, with the electric potential difference producing a net imbalance. Its tilted, material-dependent barrier is only approximated by the equal-exterior rectangular potential barrier; the exact single-particle formula above is not a complete junction model.
For the chosen model value electronvolts, . Increasing separation by multiplies by about , a reduction by about . The following diagram chooses solely for illustration; it contains no measured data and is not a fit to the 1982 curves.
Figure 1.
Vacuum-junction controls and the exponential tunnelling-current distance law
. Original tunnel junction schematic and illustrative electric current versus distance model at effective barrier energy four electronvolts. The electric current scale is chosen, the logarithm axis slope is calculated, and the apparatus is not drawn to scale. Distance sweeps and constant-current imaging are distinct operating procedures. Details.
Distance calibration is essential. In Scanning Tunneling Microscopy: From Birth to Adolescence by Gerd Binnig and others, the authors describe an initial inferred barrier near 1 eV. Recalibration found only half the quoted piezo displacement sensitivity and raised the inferred barrier above 4 eV. Thus an exponential trace alone was insufficient evidence for tunnelling through vacuum. The model makes the sensitivity explicit: the inferred depends quadratically on the distance scale.[ref]
For scanning tunnelling microscopy, feedback control adjusts the vertical position to hold electric current fixed during a lateral scan; the recorded height follows separation only when the surface is electronically homogeneous. Changes in the local density of states can also change apparent height. This limitation is already explicit in the authors' account of constant-current imaging.[ref]
